EHD Fasteners (#15)

EHD Fasteners (#15)

EHD Fastener (#15) is engineered for lap attachment to corrugated steel (18 – 22 ga.) and wood substrates in higher wind uplift roof assemblies. Featuring a #2 double flute self-drilling point and exclusive tapered entry thread design, penetrating steel quickly and offering exceptional back-out resistance.

System

EPDM
TPO
PVC
ModBit
  • #15 Extra Heavy-Duty Drill Point Fastener with buttress threads
  • May be used for membrane attachment in system warranties when greater pull strength is needed
  • A membrane fastener that can be used for attaching insulation in combination with a 3" Stress Plate
  • Must be paired with 2.4" Seam Plate when fastening membrane
  • Available in #3 Phillips head (one bit per container)
  • Not recommended for concrete, use a #14 HDP Fastener instead
  • Meets  UL Standards
  • Meets  FM Standards
  • Meets  Miami-Dade-County Standards
  • Meets  ICC-ES Standards

Documents

PDS EHD Fasteners-15
SDS - Statement for Article Products

Single-Ply Roofing Accessories Guide
Tech Bulletin Guidelines for Fastener Pull Tests
